| Project | Indicators | |||||
|---|---|---|---|---|---|---|
| Range Capability | 3km | |||||
| Laser wavelength | 1535nm±5nm | |||||
| Laser divergence angle | ≤0.5mard | |||||
| Continuous ranging frequency | 1~10Hz adjustable | |||||
| Distance measurement accuracy | ≤±1m（RMS） | |||||
| Accuracy Rate | ≥98% | |||||
| Minimum measurement range | ≤20m | |||||
| Distance measurement resolution | ≤30m | |||||
| Power supply | DC6V~36V | |||||
| Weight | ≤35g | |||||
| Power consumption | Average power consumption ≤1.5W (10Hz operation) Peak power consumption ≤5W Standby power consumption ≤0.3W Sleep power consumption ≤2mW |
|||||
| Dimensions(L×W×H) | ≤48×21×31mm | |||||
| Operating temperature | -40~+65°C | |||||
| Storage temperature | -50~+70°C | |||||
